5–54 Maintenance and Service Guide
Removal and Replacement Procedures
5.17 Modem Board
✎
The modem board cannot be removed from Compaq Presario
V4000 models until after the system board has been removed.
1. Prepare the notebook for disassembly (Section 5.3)
and remove the following components:
a. Hard drive (Section 5.4)
b. Switch cover (Section 5.12)
c. Keyboard (Section 5.13)
d. Display assembly (Section 5.14)
e. Top cover (HP Pavilion dv4000 models, Section 5.15)
f. Base enclosure (Compaq Presario V4000 models,
Section 5.16)
Modem Board Spare Part Number Information
Modem board (high-speed 56kbps) 384623-001
