Removal and Replacement Procedures
Maintenance and Service Guide 5–25
4. Turn the notebook right-side up with the front toward you.
5. Open the notebook as far as possible.
6. Press and hold down the
insert key 1.
7. Insert a flat blade tool into the notch in the switch cover
behind the
insert key and lift the switch cover up 2.
8. Disengage the center 3 and left side 4 of the switch cover
from the notebook.
9. Rest the switch cover on the notebook.
Releasing the Switch Cover
5.13 Keyboard
