5–74 Maintenance and Service Guide
Removal and Replacement Procedures
5.21 USB Board
✎
This section applies to Compaq Presario V4000 models. Refer
to steps 11 through 18 in Section 5.18, “System Board,” for
instructions for removing the USB board and frame on
HP Pavilion dv4000 models.
1. Prepare the notebook for disassembly (Section 5.3)
and remove the following components:
a. Hard drive (Section 5.4)
b. Switch cover (Section 5.12)
c. Keyboard (Section 5.13)
d. Display assembly (Section 5.14)
e. Top cover (HP Pavilion dv4000 models, Section 5.15)
f. Base enclosure (Compaq Presario V4000 models,
Section 5.16)
g. System board (Section 5.18)
2. Position the top cover with the left side toward you.
USB Board Spare Part Number Information
USB board (includes frame) 384625-001

HP Pavilion dv4000 Specifications

General

Display	15.4-inch WXGA or WSXGA+
Operating System	Windows XP Home or Professional
Processor	Intel Pentium M or Intel Celeron M
Display Resolution	1280 x 800 or 1680 x 1050
RAM	256 MB to 2 GB
Storage	40 GB to 100 GB HDD
Graphics	Intel GMA 900 or ATI Mobility Radeon
Optical Drive	DVD±RW
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone, IEEE 1394
Wireless	802.11b/g
Battery Life	Up to 3 hours
