Removal and Replacement Procedures
Maintenance and Service Guide 5–31
5. Disconnect the wireless antenna cables from the Mini PCI
communications card 1.
6. Remove the cables from the clip 2 in the base enclosure.
7. Remove the 2 Phillips PM2.5×7.0 screws 3 that secure the
display assembly to the notebook.
Removing the Display Screws
