HP Pavilion dv4000 User Manual

5–58 Maintenance and Service Guide
Removal and Replacement Procedures
✎
Steps 4 through 18 apply to HP Pavilion dv4000 models. See
steps 19 through 24 in this section to remove the system board
on Compaq Presario V4000 models.
4. Turn the notebook top side up with the front toward you.
5. Remove the following screws:
1 Three Phillips PM2.5×7.0 screws that secure the system
board and shield to the notebook
2 Two Phillips PM2.0×4.0 screws that secure the system
board and shield to the notebook
3 Two Phillips PM2.0×16.0 screws that secure the system
board, shield, and USB board to the notebook
4 One Phillips PM2.5×7.0 screw that secures the USB board
to the notebook
Removing the System Board Screws, HP Pavilion dv4000 Models

HP Pavilion dv4000 Specifications

General

Display	15.4-inch WXGA or WSXGA+
Operating System	Windows XP Home or Professional
Processor	Intel Pentium M or Intel Celeron M
Display Resolution	1280 x 800 or 1680 x 1050
RAM	256 MB to 2 GB
Storage	40 GB to 100 GB HDD
Graphics	Intel GMA 900 or ATI Mobility Radeon
Optical Drive	DVD±RW
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone, IEEE 1394
Wireless	802.11b/g
Battery Life	Up to 3 hours
