HP Pavilion dv4000 User Manual

5–62 Maintenance and Service Guide
Removal and Replacement Procedures
✎
Steps 11 through 18 provide instructions for removing the USB
board and frame on HP Pavilion dv4000 models. Refer to
Section 5.21, “USB Board,” for instructions on removing the
USB board and frame on Compaq Presario V4000 models.
11. Disconnect the audio 1, USB 2, and Bluetooth cables 3
from the system board.
Disconnecting the Audio, USB, and Bluetooth Board Cables,
HP Pavilion dv4000 Models

HP Pavilion dv4000 Specifications

General

Display	15.4-inch WXGA or WSXGA+
Operating System	Windows XP Home or Professional
Processor	Intel Pentium M or Intel Celeron M
Display Resolution	1280 x 800 or 1680 x 1050
RAM	256 MB to 2 GB
Storage	40 GB to 100 GB HDD
Graphics	Intel GMA 900 or ATI Mobility Radeon
Optical Drive	DVD±RW
Ports	3 USB 2.0, VGA, S-Video, Ethernet, Modem, Headphone, Microphone, IEEE 1394
Wireless	802.11b/g
Battery Life	Up to 3 hours
