Illustrated Parts Catalog
Maintenance and Service Guide 3–13
Table 3-2
HP Pavilion dv4000
Display Assembly Subcomponent
Spare Part Number Information
Item Description
1a
1b
Display Plastics Kit, includes:
■ Display bezel
■ Display enclosure
403919-001
2 Display Panel Kit (includes display panel,
display inverter, and display cable)
403918-001
3a
3b
Display Hinge Kit, includes:
■ Display hinges (2)
■ Display release hooks (2)
403921-001
4 Wireless antenna (includes cable and board) 397924-001
Display Label Kit (not illustrated) 403925-001
Display Screw Kit (not illustrated, includes Phillips
PM2.5×7.0 screws, Phillips PM2.5×5.0 screws, and
rubber screw covers)
403923-001
