HP Pavilion dv4000 - Page 99

Removal and Replacement Procedures
Maintenance and Service Guide 5–3
Section Description # of Screws Removed
5.10 Heat sink 1 loosened to remove the
thermal cover
4 removed to remove the heat
sink
5.11 Processor 1 loosened
5.12 Switch cover 3 on Compaq Presario V4000
models
5.13 Keyboard 4
5.14 Display assembly
Display bezel
Display release hook
Display hinges
Display panel
Wireless antenna transceiver
and cable
6
6
2
6
6
0
5.15 Top cover (HP Pavilion dv4000
models)
16
5.16 Base enclosure
(Compaq Presario V4000
models)
16
5.17 Modem board 2
5.18 System board 11 on HP Pavilion dv4000
models
4 on Compaq Presario V4000
models
5.19 Fan assembly 7
5.20 Speakers 3
5.21 USB board 8
5.22 Bluetooth board 2
Disassembly Sequence Chart (Continued)
