Rear Components
Figure 1-3 Rear Components
Table 1-2 Rear Components
Component Component
1 Power Button 8 Line out
2 LED Indicator (HDD activity) 9 4 USB 2.0 ports
3 LED Indicator (Card reader activity) 10 RJ 45/Ethernet
4 6-in-1 Media Card Reader 11 Power Connector
5 2 USB 2.0 ports 12 LED Indicator (DC-IN)
6 MIC jack (IN) 13 Lock slot
7 Headphone jack (OUT)
Rear Components 3
