Webcam Module
Description Spare part number
Webcam module 665729-001
The webcam module is located at the top of the computer. It is secured with two screws and has one
connector.
Figure 7-4 Webcam module location
To remove the webcam module:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 33).
2. Remove the rear cover (see
Rear Cover on page 34).
3. Remove the two screws (1) that secure the webcam module to the computer.
Webcam Module 37
