Optical Drive
Description Spare part number
HP SuperMulti DVD Writer Drive, LIghtScribe (includes bezel) 595115-001
HP SuperMulti DVD Writer Drive, non-LightScribe (includes bezel) 657958-001
The optical drive is located on the left side of the computer (viewed from behind). It is secured with
one captive screw.
Figure 7-10 Optical drive location
To remove the optical drive:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 33).
2. Remove the rear cover (see
Rear Cover on page 34).
3. Loosen the captive Phillips screw (1) that secures the drive to the computer.
44 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
