Rear Cover
Description Spare part number
Rear cover 665478-001
Remove the one main rear cover to access internal components
To remove the rear cover:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 33).
2. Remove the two captive Phillips screws that secure the cover to the computer.
Figure 7-1 Removing the rear cover screws
34 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
