The DDR3-SDRAM SODIMMs must also:
●
support CAS latency 9 DDR3 1333 MHz (9-9-9 timing)
●
contain the mandatory Joint Electronic Device Engineering Council (JEDEC) specification
In addition, the computer supports:
●
512-Mbit, 1-Gbit, and 2-Gbit non-ECC memory technologies
●
single-sided and double-sided SODIMMS
●
SODIMMs constructed with x8 and x16 devices; SODIMMs constructed with x4 SDRAM are not
supported
NOTE: The system will not operate properly if you install unsupported SODIMMs.
To remove a memory module:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 33).
2. Remove the rear cover (see
Rear Cover on page 34).
3. Remove the system board cover (see
System Board Cover on page 49).
4. To remove a memory module, press outward on the two latches on each side of the SODIMM
(1), allow the module to lift up to about a 45-degree angle, and then pull the SODIMM out of the
socket (2).
Figure 7-21 Removing a memory module
The computer automatically recognizes the additional memory when you turn on the computer.
52 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
