NFC module
Description Spare part number
NFC module and antenna 918399-001
IMPORTANT: Make special note of each screw size and location during removal and replacement.
Before removing the NFC module, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Keyboard (select products only) (see Keyboard (select products only) on page 31)
b. Micro SIM card tray (see Micro SIM card tray on page 32)
c. MicroSD card tray (see MicroSD memory card tray on page 33)
d. Rear cover (see Rear cover on page 34)
e. Disconnect the battery (see Disconnecting the battery on page 35)
f. Kickstand (see Kickstand on page 36)
g. SSD (see SSD on page 38)
h. Display panel (see Display panel on page 45)
i. Battery (see Battery on page 49)
Remove the NFC module:
1. Remove the clear plastic tape (1) covering the NFC cable and the ngerprint reader board, and then
disconnect the cable from the ngerprint reader board (2).
2. Remove the clear plastic tape (3) securing the NFC cable to the middle frame.
NOTE: The tape can be reused.
Component replacement procedures 53
