Front webcam
Description Spare part number
Front webcam 918906-001
The front webcam is removed as part of the system board removal. See System board on page 55.
Fingerprint reader board
Description Spare part number
Fingerprint reader board (includes cable) 918398-001
Fingerprint reader blank (included with the Plastics Kit) 918392-001
IMPORTANT: Make special note of each screw size and location during removal and replacement.
Before removing the ngerprint reader board, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Keyboard (select products only) (see Keyboard (select products only) on page 31)
b. Micro SIM card tray (see Micro SIM card tray on page 32)
c. MicroSD card tray (see MicroSD memory card tray on page 33)
d. Rear cover (see Rear cover on page 34)
e. Disconnect the battery (see Disconnecting the battery on page 35)
f. Kickstand (see Kickstand on page 36)
g. SSD (see SSD on page 38)
h. Display panel (see Display panel on page 45)
i. Battery (see Battery on page 49)
j. System board (see System board on page 55)
Remove the ngerprint reader board:
CAUTION: Use care to prevent damaging the ZIF connector and ribbon cable.
1. Open the ZIF connector (1) to release the cable, and then remove the ngerprint reader board cable (2).
Component replacement procedures 59
