Table 3-1 Computer major component descriptions and part numbers
Item Component Spare part number
(1) 33.78 cm [13.3 in], display assembly (includes webcam, microphone, and wireless antennas):
250 nits, HD camera N39190-001
250 nits, HD + IR camera N39191-001
400 nits, HD camera N39192-001
400 nits, HD + IR camera N39193-001
1000 nits, privacy N39194-001
(2) Keyboard/top cover
Not backlit, HD camera N39207-xxx
Backlit, HD camera N39208-xxx
Not backlit, HD + IR camera (includes top cover camera) N39209-xxx
Backlit, HD + IR camera (includes top cover camera) N39210-xxx
Backlit, HD camera, privacy N39211-xxx
Backlit, HD + IR camera, privacy (includes top cover camera) N39212-xxx
(3) Touchpad
NOTE: The touchpad cable is available in the Cable Kit, spare part number M03431-001.
M46283-001
(4) Power connector cable M03424-001
(5) Speaker (includes speaker, cable, and rubber isolator) M03439-001
(6) Top-cover camera board (included in Camera Module Kit)
NOTE: The top-cover camera-board cable is available in the Cable Kit, spare part number
M03431-001.
N39206-001
(7) Top cover camera (included in Camera Module Kit) N39206-001
(8) Fingerprint reader (includes gasket)
NOTE: The fingerprint reader cable is available in the Cable Kit, spare part number
M03431-001.
N10075-001
(9) RTC battery (includes cable) L13694-001
(10) System board (includes integrated processor and replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows operating system
AMD Ryzen 7 PRO 7730U processor, models with an HD camera N39201-xxx
AMD Ryzen 7 PRO 7730U processor, models with an HD + IR camera N39205-xxx
AMD Ryzen 5 PRO 7530U processor, models with an HD camera N39199-xxx
AMD Ryzen 5 PRO 7530U processor, models with an HD + IR camera N39204-xxx
AMD Ryzen 7 7730U processor, models with an HD camera N39200-xxx
AMD Ryzen 7 7730U processor, models with an HD + IR camera N39203-xxx
Computer major components 17
