then AMT Options. Then select Uncongure AMT on next boot. Select Save then Yes. Select the
File menu, and then select Save Changes and Exit. Reboot the system and conrm that you want
to uncongure AMT.
j. If the optional Intel® Anti-Theft Technology (AT) was activated, contact the provider to deactivate
it.
k. If the optional Absolute® Software Computrace® management and tracking service was activated
on the notebook PC, contact the provider to deactivate it.
l. Remove all power and system batteries for at least 24 hours.
2. Remove and retain the storage drive or clear the contents of the drive.
a. Hard Disk Drive (HDD)
Clear the HDD contents by using the HP Disk Sanitizer® utility or a third party application that,
ideally, is U.S. Department of Defense (DOD) 5220.22-M approved.
To run HP Disk Sanitizer, enter BIOS Setup by powering on the system and pressing F10 when
prompted near the bottom of the display, or press ESC to display the start up menu, then press
F10. Select the Security menu and scroll down to the Utilities menu. Select Disk Sanitizer and
select the desired drive. For a higher level of protection, select Optimum.
NOTE: This process will take a long time, and the amount of time varies based on the hard drive
capacity.
b. Solid State Drive (SSD)
Clear the SSD contents by using the BIOS Setup Secure Erase command option, or by using a third
party utility designed to erase data from an SSD. To run Secure Erase, enter BIOS Setup by
powering on the system and pressing F10 when prompted near the bottom of the display. Select
the Security menu and scroll down to the Utilities menu. Select Secure Erase and select the
desired hard drive.
122 Chapter 17 Statement of Volatility

Table of Contents

Other manuals for HP ProBook 430 G2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProBook 430 G2 and is the answer not in the manual?

HP ProBook 430 G2 Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack, Grey
Country of originChina
Bus typeDMI2
SteppingD0
Tjunction100 °C
Processor cache3 MB
Processor cores2
Processor modeli5-4210U
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-4200 Mobile series
Processor socketBGA 1168
Processor threads4
Processor codenameHaswell
Processor frequency1.7 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency2.7 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations4x1, 2x4
Thermal Design Power (TDP)15 W
Maximum number of PCI Express lanes12
Motherboard chipset-
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Memory form factorSO-DIMM
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
Memory layout (slots x size)1 x 4 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
SSD interfaceSATA
Storage mediaSSD
Card reader integratedYes
Total storage capacity128 GB
Number of SSDs installed1
Display diagonal13.3 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
On-board graphics card ID0xA16
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4400
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card base frequency200 MHz
On-board graphics card dynamic frequency (max)1000 MHz
Intel segment taggingEnterprise, Professional
Audio systemDTS Sound+
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.0
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
DisplayPorts quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pointing deviceTouchpad
Recovery operating systemWindows 8.1 Pro
Operating system installedWindows 7 Professional
Processor codeSR1EF
Processor ARK ID81016
Intel TSX-NI version0.00
Processor package size40 x 24 x 1.5 mm
Intel ME Firmware Version9.5
Supported instruction setsAVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology version1.00
Battery capacity44 Wh
Battery life (max)- h
Weight and Dimensions IconWeight and Dimensions
Depth233.5 mm
Width326 mm
Weight1500 g
Height (rear)21 mm
Height (front)20 mm
