RTC battery
Description Spare part number
RTC battery 759981-001
Before removing the RTC battery, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the following components:
a. Battery (see Battery on page 30).
b. Service door (see Service door on page 31).
c. Hard drive (see Hard drive on page 32)
d. Keyboard (see Keyboard on page 40)
e. Top cover (see Top cover on page 48)
Remove the RTC battery:
1. Position the computer upright.
2. Using a at tool, pry the battery out of the socket (1).
3. Remove the battery from the socket (2).
Reverse this procedure to install the RTC battery.
Component replacement procedures 51
