Service door
Description Spare part number
Service door 768205-001
Before removing the service door, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the battery (see Battery on page 30).
To remove the service door:
1. With the battery bay away from you, loosen the service door screw (1).
2. Slide the service door away from the battery bay (2) to remove it.
Reverse these procedures to replace the service door.
Component replacement procedures 31
