3. Remove the fan from the computer (3).
Reverse this procedure to install the fan.
System board
NOTE: All system board spare part kits include replacement thermal material.
Description Spare part number
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-501: Windows 8.1 Standard operating system
xxxxxx-601: Windows 8.1 or Windows 10 operating system
Intel Core i7-5500U processor; WWAN models 798067-xxx
Intel Core i7-5500U processor; models without WWAN models 798063-xxx
Intel Core i7-4510U processor; WWAN models 768224-xxx
Intel Core i7-4510U processor; models without WWAN 768218-xxx
Intel Core i5-5300U processor; models without WWAN 798062-xxx
Intel Core i5-5300U processor; models without WWAN 798066-xxx
Intel Core i5-5200U processor; models without WWAN 798061-xxx
Intel Core i5-4310U processor; models without WWAN 768217-xxx
Intel Core i5-4210U processor; models without WWAN 768216-xxx
Intel Core i5-4210U processor; WWAN models 768222-xxx
Intel Core i3-5020U processor; WWAN models 824121-xxx
60 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
