Item Description Spare part number
(1) Display panel, 33.8-cm (13.3-inch), HD, anti-glare not spared
(2) Keyboard (includes cable)
NOTE: For a detailed list of keyboard country codes, see Keyboard on page 40.
No backlight 767470-xxx
Backlit 767476-xxx
(3) Top cover (includes touchpad assembly)
For use in models with a ngerprint reader 768213-001
For use in models without a ngerprint reader 773562-001
(4) Power button board assembly 768203-001
(5) Fingerprint reader assembly (includes cable, bracket, and bezel) 768200-001
(6) Touchpad button board 768212-001
(7) Fan 768199-001
(8) Hard drive
1-TB, 5400-rpm, 7 mm 762990-001
750-GB, 5400-rpm, 7 mm 752099-001
500-GB, 7200-rpm, 7 mm 703267-001
500-GB, 5400-rpm, 7 mm 683802-001
500-GB, 5400-rpm, 7 mm, hybrid (8-GB SSD) 732000-001
128-GB Solid-state drive 767453-001
120-GB Solid-state drive 768055-001
(9) I/O board 768204-001
(10) Speaker assembly 768210-001
(11) Power connector and cable (includes bracket) 768197-001
(12) Heat sink assembly (includes replacement thermal material)
Heat sink for use with Intel Haswell processors 768198-001
Heat sink for use with Intel Broadwell processors 807234-001
(13) RTC battery 759981-001
(14) System board (includes replacement thermal material)
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-501: Windows 8.1 Standard operating system
xxxxxx-601: Windows 8.1 or Windows 10 operating system
Intel Core i7-5500U processor; WWAN models 798067-xxx
Intel Core i7-5500U processor; models without WWAN models 798063-xxx
18 Chapter 3 Illustrated parts catalog
