2-2
Installing the Switch
Installation Procedure
Japan Power Cord
Warning
Installation Procedure
1. Prepare the installation site (page 2-3). Please see below for some
installation precautions.
2. Verify the switch passes self test (page 2-4).
3. Mount the switch (page 2-6).
4. Connect power to the switch (page 2-11).
5. Connect the network cables (page 2-11).
Installation Precautions
Follow these precautions when installing the switch.
WARNING
■ The rack or cabinet should be adequately secured to prevent it
from becoming unstable and/or falling over.
Devices installed in a rack or cabinet should be mounted as low
as possible, with the heaviest devices at the bottom and progres-
sively lighter devices installed above.
■ When wall mounting, to meet national and international safety
requirements, wall mount either with the front facing up or down.
The side vents cannot be placed up or downward.
