Index
Clear button
deleting passwords … 1-8
description … 1-8
location on switch … 1-3, 1-8
restoring factory default configuration … 1-8,
4-11
to delete password protection … 3-4
CLI prompt, console
displaying … 2-25
configuration
checking when troubleshooting … 4-3
DHCP/Bootp … 3-2
full duplex only for mini-GBICs … 2-9
IP address … 3-3
IP address, manually … 3-2
manager password … 3-2
restoring factory defaults … 1-8, 4-11
subnet mask … 3-3
Switch Setup screen … 3-2
connecting the switch to a power source … 2-19
connecting the switch to an RPS/EPS … 2-23
connector specifications … A-2
console
checking messages during
troubleshooting … 4-9
displaying the CLI prompt … 2-25
features … 2-24
how to connect in-band … 2-24
how to connect out-of-band … 2-24
serial cable connection … 2-25
Switch Setup screen … 3-2
Telnet access … 3-5
terminal configuration … 2-24
console port
location on switch … 1-3
cross-over cable
pin-out … B-8
D
deleting passwords … 1-8
description
back of switch … 1-10
front of switch … 1-3
LEDs … 1-5
switch … 1-1
desktop switch
sample topology … 2-26
DHCP
automatic switch configuration … 3-2
for in-band access … 2-24
diagnostic tests … 4-9
checking the console messages … 4-9
checking the LEDs … 4-9
end-to-end connectivity … 4-10
testing the switch only … 4-9
testing twisted-pair cabling … 4-10
downloading new switch software … 4-12
dual-personality ports
LEDs … 1-6
location on switch … 1-4
operation description … 1-4
E
electrical specifications, switch … A-1
EMC regulatory statements … C-8
environmental specifications, switch … A-1
F
factory default configuration, restoring … 1-8, 4-11
Fan Status LED … 1-6
Fault LED … 1-5
behavior during self test … 2-13
behaviors … 1-5
blinking definition … 1-6, 1-9
location on switch … 1-3
showing error conditions … 4-4
FDx LED … 1-5, 1-8
features
console … 2-24
switch … 1-11
fiber-optic cables … B-2
1000Base-LH … B-2
1000Base-LX … B-2
1000Base-SX … B-2
front of switch … 1-3
10/100Base-TX ports … 1-3
Clear button … 1-8
description … 1-3
dual-personality ports … 1-4
LEDs … 1-5
network ports … 1-4
Port LED View select button and LEDs … 1-7
Reset button … 1-8
