HP ProCurve 3400cl-48G User Manual

4-4
Troubleshooting
Diagnosing with the LEDs
Troubleshooting
Diagnosing with the LEDs
Table 4-1 shows LED patterns on the switch and the switch modules that
indicate problem conditions.
1. Check in the table for the LED pattern you see on your switch.
2. Refer to the corresponding diagnostic tip on the next few pages.
Table 4-1. LED Error Indicators
LED Pattern Indicating Problems
Diagnostic
Tips
Power Fault
Module
(Mdl)
Status/
Fault**
RPS
Status
Test
Fan
Status
Port LED
(in Link view mode)
Off with
power cord
plugged in
***** *
➊
On Prolonged On * * Prolonged On * *
➋
On Blinking
†
**Blinking
†
**
➌
On Blinking
†
* * Off Blinking
†
*
➍
On Blinking
†
See tip 5 * Blinking
†
* Blinking
†
➎
On Off * * Off * Off with cable
connected
➏
On Off * * Off * On, but the port is not
communicating
➐
On Blinking
†
*On * * *
➑
On Blinking
†
F
1
Blinking
†
B
2
Blinking
†
* Blinking
†
**
➒
* This LED is not important for the diagnosis.
†
The blinking behavior is an on/off cycle once every 1.6 seconds, approximately.
** The Module Fault LED is located on the module in the rear of the switch.
1
F - Front
2
B - Back
