2-1
Installing the Switch
2
Installing the Switch
The ProCurve Series 3400cl Switch devices come with an accessory kit that
includes the brackets for mounting the switch in a standard 19-inch telco rack,
in an equipment cabinet, and with rubber feet that can be attached so the
switch can be securely located on a horizontal surface. The brackets are
designed to allow mounting the switch in a variety of locations and orienta-
tions. This chapter shows how to install the switch.
Included Parts
The Series 3400cl Switch devices have the following components shipped with
them:
■ ProCurve Series 3400cl Switch Installation and Getting Started Guide,
this manual
■ ProCurve Product Documentation CD ROM
(contains PDF file copies of the documentation for the Series 3400cl
Switch devices, including the Management and Configuration Guide,
and for most other ProCurve switches)
■ ProCurve Manager - CD ROM and booklet
■ Read Me First
■ Customer Support/Warranty booklet
■ Console cable
■ Accessory kits
(5064-2085) for Switch
3400cl-24G
(5069-5705) for Switch
3400cl-48G
two mounting brackets two mounting brackets*
four 8-mm M4 screws to attach the mounting
brackets to the switch
eight 8-mm M4 screws to attach the
mounting brackets to the switch
four 5/8-inch number 12-24 screws to attach
the switch to a rack
four 5/8-inch number 12-24 screws to
attach the switch to a rack
four rubber feet four rubber feet
* These mounting brackets differ from the 5064-2085 mounting brackets by being longer to
support the increased depth of the 3400cl-48G product (compared to the 3400cl-24G).
