HP ProCurve Series User Manual

2-10
Installing the Switch
Installation Procedures
Installing the Switch
Removing the mini-GBICs:
Note You should disconnect the network cable from the mini-GBIC before removing
it from the switch.
Depending on when you purchased your ProCurve mini-GBIC, it may have
either of three different release mechanisms: a plastic tab on the bottom of
the mini-GBIC, a plastic collar around the mini-GBIC, or a wire bail.
To remove the mini-GBICs that have the plastic tab or plastic collar, push the
tab or collar toward the switch until you see the mini-GBIC release from the
switch (you can see it move outward slightly), and then pull it from the slot.
To remove the mini-GBICs that have the wire bail, lower the bail until it is
approximately horizontal, and then using the bail, pull the mini-GBIC from the
slot.

HP ProCurve Series Specifications

General

Series	ProCurve
Category	Switch
Ports	Varies by model
Port Speed	Varies by model
Switching Capacity	Varies by model
Forwarding Rate	Varies by model
Power Supply	Varies by model
Management	Web, CLI, SNMP
VLAN Support	Yes
Layer	Layer 2 or Layer 3, varies by model
Jumbo Frame Support	Yes
Dimensions	Varies by model
Weight	Varies by model
