Front I/O assembly
Description Spare part number
Front I/O assembly 745049-001
1. Prepare the computer for disassembly (Preparation for disassembly on page 26).
2. Remove the access panel (
Access panel on page 27).
3. Remove the front bezel (
Front bezel on page 28).
4. From the inside of the computer, disconnect the three front I/O cables from the following system
board connectors:
●
FRONTUSB 3.0
●
FRONTUSB
●
FRONT AUD
Front I/O assembly
51
