HP ProLiant BL30p

Connectors, LEDs, and Switches
Rear Panel Connectors
Use Figure 4-2 and Table 4-1 to identify ProLiant BL30p server blade rear panel connectors.
Figure 4-2: ProLiant BL30p server blade rear panel connectors
Table 4-1: ProLiant BL30p Server Blade Rear Panel
Connectors
Item Description
1 Signal connector
2 Power connector
