Hardware options installation 31
CAUTION: Be sure to connect the video adapter to the video connector, and not to the USB
connector.
2. Connect the front video adapter to the video device.
To remove the front video adapter, squeeze the top and bottom together to release the locking mechanism.
Drive options
The server supports up to four LFF hot-plug drives and up to eight SFF hot-plug drives.
The embedded storage controller supports SATA drive installation.
For SAS drive installation, do one of the following:
• Install the riser board option with embedded HP Dynamic Smart Array B320i controller (PN
685185-001).
