HP ProLiant DL380p User Manual

Component identification 14
• The PCIe2 x16 riser cage supports a maximum power of 150 W with an HP power cable. This cable
must be used for PCIe card wattages greater than 75 W.
System board components
Item Description
1
Fan connector 6
2
Systems Insight Display connector
3
Fan connector 5
4
Processor 1 DIMM slots
5
Fan connector 4
6
Front I/O connector
7
Front USB connector
8
Fan connector 3
9
First drive cage, box 2 power connector
10
Fan connector 2
11
Processor 2 DIMM slots

HP ProLiant DL380p Specifications

General

Processor	Intel Xeon E5-2600 series
Processor Sockets	2
Memory	Up to 768GB DDR3
Memory Slots	24 DIMM slots
Expansion Slots	Up to 6 PCIe 3.0 slots
Form Factor	2U rack
Storage	Up to 25 SFF or 12 LFF drive bays
RAID Support	Smart Array P420i controller, supports RAID 0, 1, 5, 6, 10, 50, 60
Network	4x 1GbE embedded ports
Power Supply	Up to 2x 460W, 750W, or 1200W PSUs
Operating System Support	Windows Server, RHEL, SUSE, VMware
