HP ProLiant DL380p User Manual

Cabling 89
17. Install the server in the rack ("Installing the server into the rack" on page 36).
18. Remove any installed hard drives ("Removing a hot-plug SAS or SATA hard drive" on page 54).
19. Install a SATA hard drive ("Installing a hot-plug SAS or SATA hard drive" on page 53) in hard drive bay
5.
20. Install hard drive blanks in any empty hard drive bays.
21. Connect each power cord to the server.
22. Connect each power cord to the power source.
23. Power up the server (on page 21).
24. Using the HP ROM-Based Setup Utility (on page 95), disable the embedded HP Smart Array P420i
Controller, if necessary.
150W PCIe power cable option
CAUTION: To prevent damage to the server or expansion boards, power down the server and
remove all AC power cords before removing or installing the PCI expansion cage.
Connect the cable as indicated:

HP ProLiant DL380p Specifications

General

Processor	Intel Xeon E5-2600 series
Processor Sockets	2
Memory	Up to 768GB DDR3
Memory Slots	24 DIMM slots
Expansion Slots	Up to 6 PCIe 3.0 slots
Form Factor	2U rack
Storage	Up to 25 SFF or 12 LFF drive bays
RAID Support	Smart Array P420i controller, supports RAID 0, 1, 5, 6, 10, 50, 60
Network	4x 1GbE embedded ports
Power Supply	Up to 2x 460W, 750W, or 1200W PSUs
Operating System Support	Windows Server, RHEL, SUSE, VMware
