HP ProLiant DL385p

Component identification 15
• FL/FH denotes full-length, full-height. HL/FH denotes half-length, full-height. LP denotes low profile.
• The riser cages support a maximum power of 150 W with an HP power cable. This cable must be used
for PCIe card wattages greater than 75 W.
System board components
Item Description
1
Fan connector 6
2
Systems Insight Display connector
3
Fan connector 5
4
Processor 1 DIMM slots
5
Fan connector 4
6
Front I/O connector
7
Front USB connector
8
Fan connector 3
