HP ProLiant DL385p User Manual

Component identification 16
Item Description
9
First drive cage
10
Fan connector 2
11
Processor 2 DIMM slots
12
Second drive cage
13
Fan connector 1
14
NMI jumper
15
Front video connector
16
Discovery services connector
17
System maintenance switch
18
SATA optical drive connector
19
Power supply backplane connector
20
USB connector
21
SD card slot
22
Secondary (processor 2) PCIe riser connector
23
SATA drive port 1
24
Processor 2 socket
25
System battery
26
TPM connector
27
Primary (processor 1) PCIe riser connector
28
Processor 1 socket
29
FlexibleLOM
30
SAS port 1i
31
SAS port 2i
32
SAS cache module connector
System maintenance switch
Position Default Function
S1
Off Off = HP iLO security is enabled.
On = HP iLO security is disabled.
S2
Off Off = System configuration can be
changed.
On = System configuration is locked.
S3
Off
Reserved
S4
Off Reserved
S5
Off Off = Power-on password is enabled.
On = Power-on password is disabled.
S6
Off Off = No function
On = ROM reads system configuration
as invalid.
S7
— Reserved
S8
— Reserved
S9
— Reserved
S10
— Reserved
S11
— Reserved
