Hardware options installation 47
10.
Open the processor socket locking lever and the retaining bracket, and then remove the processor
socket protective cover.
IMPORTANT: Be sure the processor remains inside the processor installation tool.
11. If the processor has separated from the installation tool, carefully re-insert the processor in the tool.
Handle the processor by the edges only, and do not touch the bottom of the processor, especially the
contact area.
