Installing hardware options
4-22 HP ProLiant DL585 Server User Guide
10. Route the SAS cables through the opening in the power transfer board and over
the center wall.
Figure 4-20: Connecting the SAS power cable
CAUTION: When routing cables, always be sure that the cables are not in a position
where they can be pinched or crimped.
