HP ProLiant DL80 Gen9 - Serial Label Pull Tab Information

Component identification 90
Item Description
1
USB 2.0 connector
2
Serial label pull tab ("Serial label pull tab information" on
page 90)
3
Box 2 LFF hot-plug drives
4
Box 3 LFF hot-plug drives
• 12-bay LFF hot-plug drive model
Item Description
1
Box 1 LFF hot-plug drives
2
USB 2.0 connector
3
Box 2 LFF hot-plug drives
4
Box 3 LFF hot-plug drives
Serial label pull tab information
A double-sided serial label pull tab is present in the front panel of servers using the thumbscrew rack ears.
The following server labels are attached to this pull tab:
• Top side—Server serial number label and the customer asset tag label
• Reverse side—Default iLO account information and the server QR code label
Use your mobile device to scan the QR code label to display the server mobile product page
(http://www.hpe.com/qref/dl80gen9). This page contains links to server setup information, spare
part numbers, QuickSpecs, troubleshooting resources, and other useful product links.
In servers using the quick-release latch rack ears, these server labels are attached on the external front
edge of the access panel.
