Setup 29
If you intend to use an HP Smart Array controller card option ("Installing a storage controller" on page 49),
record the model name for this procedure.
For more information about the storage controller and its features, select the relevant controller user
documentation on the HP website (http://www.hp.com/go/smartstorage/docs).
To configure arrays, see the HP Smart Storage Administrator User Guide on the HP website
(http://www.hp.com/go/smartstorage/docs).
To create a drive array:
1. On the Intelligent Provisioning main screen, click Perform Maintenance.
2. On the Maintenance screen, click HP Smart Storage Administrator (HP SSA).
The system launches the HP SSA GUI.
3. On the left-hand side of the screen, select the preferred HP Smart Array Controller device, and then click
Configure under the available options.
The Configure panel is displayed.
4. Click Create Array.
5. Select the array settings for the selected device.
6. Use the Next and Back buttons to navigate multiple screens of options.
7. Click Save or OK.
8. Click Exit HP SSA.
9. Click PREVIOUS.
Install the operating system
1. If you are installing the OS from a disc or an external USB drive, do one of the following:
o Load the OS image disc to the server optical drive. If an optical drive is not installed, connect a USB
optical drive to the server USB 2.0 connector.
o Connect the USB storage drive containing the OS image to the server USB 2.0 connector.
2. On the Intelligent Provisioning main screen, select Configure and Install.
3. The system detects the default hardware settings. Retain these settings or customize them according to
your requirements.
4. Follow the onscreen prompts to install the OS.
Complete the system setup
Check the status of the server LEDs to ensure that the server is operating normally:
System power LED Solid green
NIC status LED Solid green
Drive status LED Solid green

Table of Contents

Other manuals for HP ProLiant MicroServer Gen8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProLiant MicroServer Gen8 and is the answer not in the manual?

HP ProLiant MicroServer Gen8 Specifications

General IconGeneral
Tcase65.3 °C
Bus typeDMI
FSB ParityNo
Processor cache3 MB
Processor cores2
Processor modeli3-3240
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3200 Desktop Series
Processor threads4
Processor codenameIvy Bridge
Motherboard chipsetIntel® C204
Processor frequency3.4 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor package size37.5 x 37.5 mm
Processor front side bus- MHz
Processor operating modes64-bit
PCI Express configurations1x16, 2x8
Supported instruction setsAVX, SSE4.1, SSE4.2
Thermal Design Power (TDP)55 W
Supported processor socketsLGA 1155 (Socket H2)
Number of processors installed1
Thermal solution specificationPCG 2011C
CPU multiplier (bus/core ratio)34
Thermal Monitoring TechnologiesYes
Memory types supported by processorDDR3-SDRAM
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
HDD size3.5 \
RAID levels0, 1, 10
HDD interfaceSerial ATA
Optical drive typeDVD±RW
Total storage capacity1000 GB
Maximum storage capacity12 TB
Memory slots2x DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Maximum internal memory16 GB
Memory layout (slots x size)1 x 4 GB
On-board graphics card ID0x152
On-board graphics card modelIntel® HD Graphics 2500
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1050 MHz
Number of displays supported (on-board graphics)3
Cabling technology10/100/1000Base-T(X)
Ethernet interface typeGigabit Ethernet
Power supply200 W
Chassis typeUltra Micro Tower
Serial ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version2.0
Operating system installed-
Compatible operating systemsMicrosoft Windows Server Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware
Processor ARK ID65690
Intel Secure Key Technology version0.00
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth245 mm
Width230 mm
Height232.4 mm
Weight9800 g
