Setup 28
5.
Check the server Power LED status . The LED flashes green to indicate that power connection is
established.
6. During the initial server boot (POST), do one of the following:
o For advanced users, to modify the server configuration ROM default settings, press F9 when
prompted to enter the RBSU. By default, the RBSU runs in the English language.
o To retain the HP recommended default server configuration and install the operating system, press
F10 to initiate Intelligent Provisioning. Proceed to the next section.
For more information on automatic server configuration, see the HP ROM-Based Setup Utility User
Guide in the HP RBSU Information Library (http://www.hp.com/go/rbsu/docs).
Performing the initial system setup
HP recommends using Intelligent Provisioning to install the server operating system. All firmware, drivers, and
tools required by the system are installed during the same process.
Intelligent Provisioning provides installation help for the following operating systems: Microsoft Windows,
Red Hat and SUSE Linux, and VMware.
IMPORTANT: When installing a Windows operating system, Intelligent Provisioning can assist
with installing only the 64-bit version of the operating system.
IMPORTANT: Installing VMware ESXi or ESX requires a custom HP image, which includes the
drivers for VMware devices not included in the VMware base image. The image is available on
the HP website (http://www.hp.com/go/esxidownload).
Activate Intelligent Provisioning
Follow the prompts on the Set Preferences screen to activate Intelligent Provisioning.
If you intend to register for HP Insight Remote Support, you should have your HP Passport user name and
password ready. For more information, see the HP Insight Remote Support and Insight Online Setup Guide
for ProLiant Gen8 Servers and HP BladeSystem c-Class Enclosures on the HP website
(http://www.hp.com/go/insightremotesupport/docs).
Configure the drive

Table of Contents

Other manuals for HP ProLiant MicroServer Gen8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProLiant MicroServer Gen8 and is the answer not in the manual?

HP ProLiant MicroServer Gen8 Specifications

General IconGeneral
Tcase65.3 °C
Bus typeDMI
FSB ParityNo
Processor cache3 MB
Processor cores2
Processor modeli3-3240
System bus rate5 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-3200 Desktop Series
Processor threads4
Processor codenameIvy Bridge
Motherboard chipsetIntel® C204
Processor frequency3.4 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor package size37.5 x 37.5 mm
Processor front side bus- MHz
Processor operating modes64-bit
PCI Express configurations1x16, 2x8
Supported instruction setsAVX, SSE4.1, SSE4.2
Thermal Design Power (TDP)55 W
Supported processor socketsLGA 1155 (Socket H2)
Number of processors installed1
Thermal solution specificationPCG 2011C
CPU multiplier (bus/core ratio)34
Thermal Monitoring TechnologiesYes
Memory types supported by processorDDR3-SDRAM
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600 MHz
Memory bandwidth supported by processor (max)25.6 GB/s
Maximum internal memory supported by processor32 GB
HDD size3.5 \
RAID levels0, 1, 10
HDD interfaceSerial ATA
Optical drive typeDVD±RW
Total storage capacity1000 GB
Maximum storage capacity12 TB
Memory slots2x DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Maximum internal memory16 GB
Memory layout (slots x size)1 x 4 GB
On-board graphics card ID0x152
On-board graphics card modelIntel® HD Graphics 2500
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1050 MHz
Number of displays supported (on-board graphics)3
Cabling technology10/100/1000Base-T(X)
Ethernet interface typeGigabit Ethernet
Power supply200 W
Chassis typeUltra Micro Tower
Serial ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express slots version2.0
Operating system installed-
Compatible operating systemsMicrosoft Windows Server Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware
Processor ARK ID65690
Intel Secure Key Technology version0.00
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth245 mm
Width230 mm
Height232.4 mm
Weight9800 g
