Cabling 65
Optical drive cabling
Item Description
1
4-pin power connector (connected to the PSU P3 cable) of the optical
drive SATA Y-cable
2
Common end of the optical drive SATA Y-cable
3
SATA connector of the optical drive SATA Y-cable
Front I/O assembly cabling
