HP ProLiant MicroServer Installation Sheet

Identifying server components
Front panel components
Item Component
1
NIC LED
2
Hard Disk Drive LED
3
Power Button
4
USB Ports
5
Health LED
6 Panel door lock
Panel door components
Item Component
1 16 screws for HDD installation
2 4 screws for ODD installation
3 Screw driver
Rear panel components
Item Component Item Component
1 Power Supply Outlet 2 PSU Fan
3 PCI Holder 4a PCI Bracket 1
4b PCI Bracket 2 5 e-SATA Connector
6 Rear USB 2.0 Ports 7 VGA Port
8 Embedded NIC Port 9 Rear System Fan
10 Kensington Lock
