HP ProLiant ML10 Maintenance And Service Guide

Illustrated parts catalog 18
Item Description Spare part
number
Customer self
repair (on
page
5
)
2
300 W Integrated power supply 732598-001 Mandatory
1
3
System fan 732595-001 Mandatory
1
4
Heatsink and fan
732596-001
Mandatory
1
5
Processor (includes alcohol pad and thermal
compound)
— —
a) 3.10-GHz Intel Xeon E3-1220 v2
processor, 4 C, 8 MB, 69 W
686686-001 Optional
2
b) 3.20-GHz Intel Pentium G2130 processor,
2 C, 3 MB, 55 W*
715898-001 Optional
2
6
System board assembly 732594-001 Optional
2
7
DIMMs — —
a) 2 GB PC3-12800E, 256Mx8 684033-001 Mandatory
1
b) 4 GB PC3-12800E, 256Mx8* 684034-001 Mandatory
1
c) 8 GB PC3-12800E, 512Mx8* 684035-001 Mandatory
1
8
LFF non-hot-plug SATA drives — —
a) 500 GB, 3G drive
459316-001
Mandatory
1
b) 1 TB, 3G drive* 508039-001 Mandatory
1
c) 2 TB, 3G drive* 508041-001 Mandatory
1
9
Optical drive — —
a) SATA ROM drive 624591-001 Mandatory
1
b) SATA RW drive 624592-001 Mandatory
1
10
Drive enablement kit* 732593-001 Mandatory
1
a) 220 mm SATA cable* 730645-002 Mandatory
1
b) T-15, 6-32 screws (4)* 482298-003 Mandatory
1
c) M3 screws (2)* 247348-001 Mandatory
1
d) 1 LFF drive carrier* 744240-001 Mandatory
1
11
4 LFF Drive enablement kit* 743250-001 Mandatory
1
a) 1 LFF drive carrier* 744240-001 Mandatory
1
b) 3 LFF drive bracket* 742975-001 Mandatory
1
c)3 LFF drive carrier* 742974-001 Mandatory
1
d) Shoulder screws (8)* 742977-001 Mandatory
1
e) M3 screws (2) (black)* 247348-001 Mandatory
1
f) T-15, 6-32 screws (20)* 482298-003 Mandatory
1
g) Mini-SAS/power cable assembly* 742976-001 Mandatory
1
h) 220mm SATA cable*
730645-002
Mandatory
1
i) Thermal grease* 390717-002 Mandatory
1
12
Cable kit* 732599-001 Mandatory
1
a) Ambient temperature sensor cable* 731213-001 Mandatory
1

HP ProLiant ML10 Specifications

General

Memory Slots	4
Form Factor	Tower
Processor	Intel Xeon E3-1200 v3
Memory	Up to 32 GB
Drive Bays	4 LFF
Power Supply	300W
Chipset	Intel C222
Expansion Slots	1 PCIe 3.0 x16, 1 PCIe 2.0 x1
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
RAID Support	Integrated SATA RAID controller (Intel Rapid Storage Controller); optional HP Smart Array controllers
