Hardware options installation 25
b.
Pull the cables out.
9. Remove the drive:
a. Unfasten and remove the four T-15 screws connected to the drive cage.
b. Slide out the drive to remove it.
10. Disconnect the 24 pin power supply cable:
a. Release the cable tie securing the 24 pin power supply cable.
