Specifications 60
Specifications
Environmental specifications
Specification Value
Temperature range*
Operating
10
°
C to 35
°
C (50
°
F to 95
°
F)
Nonoperating
-30° C to 60° C (-22° F to 140° F)
Relative humidity
(noncondensing)
Operating, maximum wet bulb
temperature of 28°C (82.4°F)
10% to 90%
Nonoperating, maximum wet
bulb temperature of 38.7°C
(101.7°F)
5% to 95%
* All temperature ratings shown are for sea level. An altitude derating of 1° C per 304.8 m (1.8° F per 1,000 ft) to 3048
m (10,000 ft) is applicable. No direct sunlight allowed.
Server specifications
Specification Value
Dimensions
Height
36.39 cm (14.3 in)
Depth
38.1 cm (15 in)
Width
16.5 cm (6.5 in)
Weight
5.94 kg (13.08 lb)
Power supply specifications
The server supports one HP 300 W Integrated Power Supply.
CAUTION: Check the system and power supply input ratings before powering up the server.
Specification Value
Input requirements
Rated input voltage
100 V to 240 V
Rated input frequency
50Hz to 60Hz
Rated input current
4 A at 100 VAC to 200 VAC

Table of Contents

Other manuals for HP ProLiant ML10

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProLiant ML10 and is the answer not in the manual?

HP ProLiant ML10 Specifications

General IconGeneral
Memory Slots4
Form FactorTower
ProcessorIntel Xeon E3-1200 v3
MemoryUp to 32 GB
Drive Bays4 LFF
Power Supply300W
ChipsetIntel C222
Expansion Slots1 PCIe 3.0 x16, 1 PCIe 2.0 x1
Operating System SupportWindows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
RAID SupportIntegrated SATA RAID controller (Intel Rapid Storage Controller); optional HP Smart Array controllers
