Component identification 8
Rear panel LEDs and buttons
Item Description Status
1
NIC status LED Solid green = Link to network
Flashing green (1 Hz/cycle per sec) = Network active
Off = No network activity
2
NIC link LED Solid green = Link exists
Off = No link exists
3
Power supply LED
Off = No power present
System board components
