Hardware options installation 68
1. Identify the redundant power supply bay ("Rear panel components" on page 9).
IMPORTANT: Power supplies for the model shown are hot-pluggable. When using the redundant
power supply option, it is not necessary to power down the server before removing or installing
a power supply.
2. Remove the power supply blank.
WARNING: To reduce the risk of electric shock or damage to the equipment, do not connect AC
power cords to uninstalled power supplies.
3. Slide the power supply into the power supply bay until the release/lock lever clicks, securing the power
supply.
4. Connect the power cord to the power supply.
5. Using the retaining clip shipped with the server, secure the power cord to the power supply handle.
Securing the cord will ensure enough slack.
6. Connect the power cord to the AC power source.
7. Be sure that the power supply LED is illuminated green ("Rear panel LEDs and buttons" on page 10).
