HP R/T3000 G4 INTL User Manual

Page 22
792519-001 Edition 1
ENGLISH
3. Installation
Mounting ERM on the rails
Follow steps 1 through 4 for mounting the ERM on the rails.
M3 screws
M3 screws
M3 screws
M6 screws
M6 screws
M6 screws
M6 screws
M6 screws
M6 screws
4
4
3
3
2
2
1
1
3.8 ERM and UPS installation
There are two ERM models. They can be installed with UPSs in both rack and tower installations. Up to four ERMs
can be installed with each UPS.
HP R/T3000 G4 ERM
HP R/T2200 G4 ERM

HP R/T3000 G4 INTL Specifications

General

Input Frequency	50/60 Hz
Output Connections	(8) IEC 320 C13, (1) IEC 320 C19
Input Connection Type	IEC 320 C20
Rack Height	2U
Battery Type	Sealed Lead Acid (SLA)
Battery Recharge Time	3 hours
Operating Humidity	0% to 95% non-condensing
Output Power Capacity	2700 W
Form Factor	Rackmount/Tower
Interface Ports	USB, Serial
Operating Temperature	0°C to 40°C
