2.3 Display functions
Press the button to activate the menu options. Use the and buttons to scroll through the menu structure. Press
the button to select an option. Press the button to cancel or return to the previous menu.
Menu map for Display Functions.
Main menu Submenu Display information or Menu function
Measurements
—
Load W VA / Load A pf / Output V Hz / Input V Hz /
Battery V min / Efficiency / Power usage
Control Load Segments Group 1: ON / OFF
Group 2: ON / OFF
These commands overrule user settings for load segments.
Start battery test Starts a manual battery test
Reset fault state Clears active fault (UPS restart required)
Restore factory settings Returns all settings to original values
Reset power usage Clears power usage measurements
Settings Local settings
Sets general parameters
Input / output settings Sets Input and output parameters
ON / OFF settings
Sets on and off conditions
Battery settings Sets battery configuration
Fault log
—
Displays event log or alarms
Identification
— UPS Type/Part Number/Serial Number/Firmware release/Com card
address
2.4 User settings
The following table displays the options that can be changed by the user.
Description
Available settings
Default settings
Local settings
Language
[English] [French] [German] [Spanish]
[Italian] [Portuguese] [Russian]
Menus, status, notices and alarms, UPS
fault, event log data and settings are in all
supported languages.
English
User selectable when the UPS
is powered the first time.
LCD settings Allows LCD screen brightness and contrast
to be adapted to room light conditions.
—
Audible alarm [Enabled] [Disabled on battery] [Always
disabled]
Allows you to enable or disable the audio
alarm if an alarm occurs.
Yes
In/Out settings
Output voltage Low voltage: [100V] [120V] [125V]
High voltage: [200V] [208V] [220V]
[230V] [240V]
User selectable when UPS is
powered for the first time.
Input thresholds [Normal mode] [Extended mode]
Extended mode reduces lower input volt-
age to 70V before UPS transfers to battery.
This can be used if the load can
withstand low voltage supply.
Normal mode
Sensitivity [High] [Low]
High: For sensitive equipment, the
UPS will easily transfer to battery when
utility conditions deteriorate.
Low: For less sensitive equipment, the UPS
will not transfer to battery when utility
conditions deteriorate.
High
Load segments - Auto
start delay
[No Delay] [1 s] [2 s]…[65354 s]
The connected equipment is powered
after the specified delay.
Group 1: 3 s
Group 2: 6 s
Continued
