Specifications 52
Feature Specification
Voltage wave shape
Sine wave; 5% THD with typical PFC load
Surge suppression
High-energy 6500 A peak
Noise filtering
MOVs and line filter for normal and common mode
use
Battery specifications
Feature Specification
Type
Each model contains maintenance-free, sealed, valve
regulated lead-acid batteries with an 8-year minimum float
service life at 25°C (77°F).
Voltage
The battery modules have a battery string voltage of 216 V.
Charging
Complete charge takes no more than 48 hours.
Approximately 3 hours to 80 percent capacity at default
nominal utility voltage and no load.
Average battery runtime
Average battery runtimes are approximate and vary depending on connected equipment, configuration,
battery age, temperature, and so on. These estimates are based on the batteries at beginning of life.
Load % Estimated battery
runtime (minutes)
Runtime with one
ERM (minutes)
Runtime with four
ERMs (minutes)
NA/JPN INTL NA/JPN INTL NA/JPN INTL
20
52 62 98 117 301 359
50
13 15 33 37 103 115
80
6 7 18 21 57 66
100
4 5 13 15 39 50
Minimum battery runtime
Minimum battery runtimes are at beginning of life.
Load % Internal battery runtime
(minutes)
Runtime with one
ERM (minutes)
Runtime with four
ERMs (minutes)
NA/JPN INTL NA/JPN INTL NA/JPN INTL
20
42 50 80 95 240 300
50
10 12 27 30 80 95
80
5 6 16 18 52 60
100
3 4 11 13 35 45
