Chapter 2 Description
6
Heavy-Duty Casters
Each System/E is provided with four,
7.6 cm (3 in) diameter, smooth rolling,
heavy-duty urethane casters to facilitate
moves over short distances. The casters
are rated at 454.5 kg (1000 lbs) per
caster.
CAUTION A fully loaded cabinet’s maximum gross weight of 995 kg (2188 lbs) can
overload a raised floor.
Leveling Feet
Four adjustable leveling feet come with
the rack for stability and leveling.
Levelers are located in each corner to
level and stabilize the rack. For
maximum accuracy, use a level while
adjusting the feet.
Rear Door
The rear door comes installed from the
factory. Standard is a right-opening,
perforated rear door with a lockable
slam latch and sheetmetal catch
providing ventilation and security. The
rear door can be mounted to open from
either the left or the right. They are
perforated for maximum airflow. They
lift on and off their hinges when open to
about 45 degrees. The 1.96 m door
weighs 11.8 kg (26 lbs). The 1.6 m rear
door weighs 9.1 kg (20 lbs). The 1.25 m
rear door weighs 7.7 kg (17 lbs).
