Table 11 HP SN6000B 16Gb FC Switch power supply specifications (continued)
ValuesSpecification
Maximum of 50 A peak at 240 VAC for any initial current surge or spike of
10 ms or less at cold start up. Additional inrush current surges or spikes in
Inrush current
the form of AC cycles, or multiple AC cycles greater than 10 ms and less
than 150 ms, must not exceed 15 A peak.
150 W at 12 VDCSingle power supply output
12.5 A at 12 VDCMaximum current
Both AC lines fusedInput line protection
110 W with all 48 ports populated with 16 Gb/s SWL optical mediaSystem power consumption
72 W with empty chassis and no optical media
Table 12 HP SN3000B 16Gb FC Switch power supply specifications
ValuesSpecification
Range: 85–264 VAC, nominal: 100–240 VACInput voltage
Range: 47–63 Hz; Nominal: 50–60 HzInput frequency
Maximum of 35 A peak at 240 VAC for 10 ms or lessInrush current
150 W at 12 VDCSingle power supply output
AC lines are fusedInput line protection
80 W with all 24 ports populated with 16 Gb/s SWL optical mediaSystem power consumption
60 W with empty chassis and no optical media
Environmental requirements
Table 13 (page 47) lists the acceptable environmental ranges for both operating and nonoperating
(such as during transportation or storage) conditions.
Table 13 Environmental requirements
Acceptable range during nonoperationAcceptable range during operationCondition
-25º to 70ºC (-13º to 158ºF)0º to 40ºC (32º to 104ºF)Ambient
temperature
10% to 90% RH non-condensing, at 70ºC (158ºF)10% to 85% RH non-condensing, at 40ºC (104ºF)Humidity
0 to 12 km (39,370 ft) above sea level0 to 3 km (9,842 ft) above sea levelAltitude
33 G, 11 ms, half-sine wave, 3/e.g. Axis20 G, 6 ms, half-sine waveShock
2.0 G sine, 1.1 gms random, 5–500 Hz0.5 G sine, 0.4 gms random, 5–500 HzVibration
N/AMaximum - 71.36 cubic m/h (42 cubic ft/m)Airflow
Nominal - 59.47 cubic m/h (35 cubic f/m)
N/A338 BTU/hr (32-port configuration)Heat dissipation
375 BTU/hr (48-port configuration)
Environmental requirements 47
